ARACHNE X6

당사의 표준이 귀사의 요구사항에 맞지 않나요?
저희에게 연락하여 솔루션을 설계하세요!

SKU AR-X6 Category

ARACHNE X6

In Stock

ARACHNE X6 – Load up to 100 Kg (220 Lb) The ARACHNE X6 is LHD patented solution and doesn’t need a cable carrier to drive fingers. For this reason, its dimension is the smallest on the market, just 180×50 mm. Like ARACHNE X6 can carry out the handling of two plastic boxes (or carton) about as big as 600×400 mm with 100 Kg weight, in simple or in double depth, or 2 of these boxes in single depth. Onboard is possible, single belt, double belts, sheet flat, single rolls conveyor, width adjustment, automatic bridge to avoid the gap between shelf and system.

Description

ARACHNE X6
Carton Loader – Load up to 100 kg (220 Lb)

Standard length: from 900 mm to 1350 mm
Maximum stroke: from 1000 mm to 1450 mm
Maximum payload: 2x 50 Kg
Acceleration without load: up to 1 [m/s2]
Speed without load: up to 45 [m/min]
