ARACHNE XX4

In Stock

ARACHNE XX4 – Load up to 50 kg (110 Lb) The ARACHNE XX4 is a patented double-depth solution in rack, one box on board. The ARACHNE can carry out the handling of one plastic box (or carton) about as big as 600×400 mm with 50 Kg weight. In the picking phase, two telescopic arms reach the load on the shelf and, by means of small pivoting fingers, drag it onboard the shuttle. The single belt system on board the XX4 version can handle one box at once. On board is possible: single belt, double belts, sheet flat, single rolls conveyor, width adjustment, automatic bridge to avoid gap between shelf and system. With his telescopic arms thickness of only 74 mm, ARACHNE allows reducing the spaces between the boxes in the cells, thus reducing the width of the whole shelf.

Description

ARACHNE XX4
Carton Loader – Load up to 50 kg (110 Lb)

Standard length: from 700 mm to 1300 mm
Maximum stroke: from 1400 mm to 2400 mm
Maximum payload: 50 kg (110 Lb)
Acceleration without load: up to 1 [m/s2]
Speed without load: up to 45 [m/min]
