ATHENA 110

我们的标准不符合您的需求?
联系我们,设计您的解决方案!

SKU AT110 Category

ATHENA 110

In Stock

ATHENA 110 – Load up to 2500 Kg (5515 Lb) Like every product from the LHD Group: this Load Handling Device has been designed by the LHD Engineering team and assembled by the LHD Manufacturing Team. Intermediate fork of the ATHENA series, it’s a very versatile and safe piece of equipment. It can rely on a solid structure with a remarkably small bending. Among its many applications, there is the possibility to be installed upside down, for special purposes. Thanks to its outstanding performances it’s the most used fork of this series because despite its toughness it preserves good operating speed and working paces. It’s fit for the same operating sectors as the ATHENA 100, and as far as transmission is concerned, it’s available both with racks and pinions and with chains. The type of environment and the modes in which they are intended to work determine the choice. For this reason, we recommend consulting the technical LHD S.p.A. staff before making this choice. All LHD Group’s telescopic forks undergo accurate run tests and quality checks before delivery.

Clear

Description

ATHENA 110
Single depth – Load up to 2500 Kg (5515 Lb)

Standard length: from 1100 mm to 2500 mm
Stroke: from 1200 to 2600 mm
Load: up to 2500 Kg (5515 Lb)
Cross Section:  W x H = 200 x 110 mm
Speed without load: 45 m/min
Acceleration without load: 1 m/s2
2 (two versions): gear and rack version and chain version

Specification

下叉长

, , , , , ,

负载

,

满载最大弯曲

, , , , , ,

行程

, , , , , ,

上叉长

, , , , , ,
