ATHENA 183

Out of Stock

ATHENA 183 – Load up to 5000 Kg (11025 Lb) Like every product from the LHD Group: this Load Handling Device has been designed by the LHD Engineering team and assembled by the LHD Manufacturing Team. This model of the ATHENA series is particularly suitable for handling heavy loads with long strokes and low bending. Due to its considerable weight, it’s designed for on-site maintenance: all components prone to wear and tear can be replaced without removing the fork from its operating site. Its version with inclined slides is expressly designed to handle big size coils. The ATHENA series can be produced also in notably bigger sizes, nevertheless, it’s part of the custom-built production and its feasibility has to be established along with LHD S.p.A.’s technical staff. All LHD Group’s telescopic forks undergo accurate run tests and quality checks before delivery.

Clear

Description

ATHENA 183
Single depth – Load up to 5000 Kg (11025 Lb)

Standard length: from 1500 mm to 3000 mm
Stroke: from 1600 to 3200 mm
Load: up to 5000 kg (11025 Lb)
Cross Section:  W x H = 370 x 183 mm
Speed without load: 30 m/min
Acceleration without load: 0,5 m/s^2

Specification

下叉长

, , , , , ,

负载

,

满载最大弯曲

, , , , ,

行程

, , , , , ,

上叉长

, , , , , ,
