PHOEBUS X2

我们的标准不符合您的需求?
联系我们,设计您的解决方案!

SKU PH-X2 Category

PHOEBUS X2

In Stock

PHOEBUS X2 – Load up to 100 Kg (220 Lb) Designed for backing up the telescopic forks, the two lateral belt conveyor allows moving the loads onboard simultaneously. The fork set can pick up the load from the shelf, and then the PHOEBUS can lay it down in the unloading bay with no further need of telescopic stroke. The number of belts can be redoubled, thus making it even more flexible and versatile – it can also handle a double load onboard. Therefore, it’s possible to halve the operation time by handling two loads at once. The same system can involve chains instead of belts, to handle way bigger loads with the same benefits.

Description

PHOEBUS X2
Unit transfer – Load up to 100 Kg(220 Lb)

Standard length: from 650 mm to 1250 mm
Maximum payload: 2 x 50 kg (2 x 110 Lb)
Acceleration without load: up to 1 [m/s2]
Speed without load: up to 45 [m/min]
