ZEUS 65-165


SKU Z65-165 Category

ZEUS 65-165

Out of Stock

ZEUS 65-165 – Load up to 1200 Kg (2646 Lb) Like every product from the LHD Group: this Load Handling Device has been designed by the LHD Engineering team and assembled by the LHD Manufacturing Team. This is the queen of all LHD S.p.A.’s Telescopic forks, thanks to both its performances and its versatility. Its small size, operating speed and small bending when picking up/laying down the load makes the ZEUS 65-165 an essential piece of equipment for those who want to be performing and competitive in their sector. Backed up by its components – that are not extruded or assembled, but rather milled from a whole-piece – the ZEUS 65-165 telescopic fork, with both engines operating independently, allows to take advantage of the operating site at its best by optimizing the stroke movements even in narrow required spaces, in both depths. It also doesn`t request to lay the load located in the single depth position on mounts, since the upper slide can operate alone. It`s only available with chain transmission. To establish the size of these telescopic forks we suggest consulting LHD S.p.A.’s technical staff. All LHD Group’s telescopic forks undergo accurate run tests and quality checks before delivery.



ZEUS 65-165
Double Depth – Load up to 1200 Kg (2646 Lb)

Standard length: from 1000 mm to 1500 mm
Stroke: from 1900 to 3000 mm
Load: up to 1200 Kg (2646 Lb)
Single depth cross section:  W x H = 172 x 65 mm
Double depth cross section:  W x H = 172 x 165 mm
Speed without load: 45 m/min
Acceleration without load: 1 m/s2



, , , , , , , ,


, , , , , ,


, , ,


, , , ,


, , , , ,


, , , , , ,
