ZEUS 70-172

我们的标准不符合您的需求?
联系我们,设计您的解决方案!

SKU Z70-172 Category

ZEUS 70-172

In Stock

ZEUS 70-172 – Load up to 1300 Kg (2867 Lb) Like every product from the LHD Group: this Load Handling Device has been designed by the LHD Engineering team and assembled by the LHD Manufacturing Team. It`s an enhanced version of the ZEUS 65-165. It keeps all the peculiar features of the smaller sister, but with a higher carrying capacity. It`s not particularly fit for conventional warehouses, but for storage plants within bigger production facilities. Its shape allows attaining the highest moment of inertia of all telescopic forks currently on the market. It`s available with chain transmission. To establish the size of these telescopic forks we suggest to consult LHD S.p.A.`s technical staff. All LHD Group’s telescopic forks undergo accurate run tests and quality checks before delivery.

Clear

Description

ZEUS 70-172
Double Depth – Load up to 1300 Kg (2867 Lb)

Standard length: from 1100 mm to 1800 mm
Stroke: from 2300 to 3300 mm
Load: up to 1300 Kg (2867 Lb)
Single depth cross section:  W x H = 172 x 70 mm
Double depth cross section:  W x H = 172 x 172 mm
Speed without load: 45 m/min
Acceleration without load: 1 m/s^2

Specification

双深行程

, , , , , , , ,

下叉长

, , , , , ,

负载

, ,

双深满载挠度

, , , , ,

单深满载挠度

, , , , ,

行程

, , , , , ,

上叉长

, ,
